Pentode
Introduced in 1933
| 1 |
2 |
3 |
4 |
5 |
6 |
| f |
g2 |
f |
g1 |
k |
a |
|
Vf |
Af |
Va |
Vs |
Vg |
mAa |
mAs |
ra |
gm |
| 4 |
1.1 |
200 |
100 |
-2 |
5 |
1.25 |
1,000,000 |
3.5 |
| Equivalent |
5-447, AF2,
AS4100, E447, H4129D,
HP4105, HP4106,
KL70701S, MT4110,
MVSPen,
RENS1294, RS4347, T4700,
TE47, TF2, VMP4,
VP4,
W519, WE25 |
|
|
|
