Pentode
Introduced 1953
| 1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
Base |
| i.c. |
g1 |
k,g3 |
f |
f |
i.c. |
a |
i.c. |
g2 |
B9A |
|
Vf |
Af |
Va |
Vs |
Vg |
mAa |
mAs |
ra |
gm |
Pout |
Pdiss |
|
6.3 |
0.76 |
250 |
250 |
-7.3 |
48 |
5.5 |
40,000 |
11.3 |
5.7 |
12 |
| Equivalent |
6BQ5, 6P14P, 6P15, CV10321,
CV2975, CV8069, E84L,
EL84, E84L, EL84M, N709 |
|
|
|
