| 1 |
2 |
3 |
4 |
5 |
top |
voet/base |
| g2 |
f |
f |
g1 |
k |
a |
B5 |
Tetrode
Introduced in
1928
| Vf |
Af |
Va |
Vs |
Vg |
mAa |
mAs |
Ri |
gm |
Pdiss |
| 4 |
0,9 |
150-200 |
100 |
-1.3 |
1.5 |
0.6 |
800,000 |
1 |
1 |
| Equivalents |
4610, 5-442, AS494, DN2004, DW6,
H4080D, H4100D, I4091, MS4, NC4,
RENS1204, RS4142, S4150, S4V, W409 |
|
|
